Encentrum marinum; the arrow points to the characteristic light-refracting body in the subcerebral glands (arrow). The intestinum of this specimen from a saltwater source (2) contains presumably digested green algae (Enteromorpha sp.). (2) |
|
 |
Encentrum marinum; dorsoventrall view. The arrowheads point to the light-refracting bodies. In contrast to other animals presented here this specimen was found in a freshwater environment. (1) |
|
 |
Encentrum marinum; dorsoventral view, focus plane on the forcipate trophi. (1) |
|
 |
Encentrum marinum; the tweezer-like trophi can be protruded to catch the prey; specimen from (6) |
|
|
Encentrum marinum; left image: this dorsoventral view of the head shows the light-refracting bodies in the subcerebral glands (1). Right image: forcipate trophi. (1) |
|
 |
Encentrum marinum; specimen with amictic egg. (1) |
|
|
 |
Encentrum marinum; specimen from (2), feeding exclusively on small flagellates (Bodo?) |
|
|
Encentrum marinum; left: trophi of specimen from (6); right: trophi of specimen from (7). the intramallei look different in |
|
|
 |
Encentrum marinum; feeding some micro-algae which were very abundant in this habitat. In contrast to animals from other habitats the specimens from this population have very short toes. (7) |
|
 |
Encentrum marinum; same specimen with protruded trophi. ( 7) |
|
 |
Encentrum marinum; same specimen focus plane on a ring of motile cilia of the corona (arrowheads) (7) |
|
 |
Encentrum marinum; specimen from (3), lateral view |
|
 |
Encentrum marinum; specimen from (4), slightly compressed by coverslide; head retracted. |
|
 |
Encentrum marinum; another specimen, lateral view, from (5). |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Location: Bad Frankenhausen; Kyffhäuser, Elisabethquelle (2); Aber Benoit, Treglonou, Britanny, France (3); Hiddensee, Siel (4); Hollum, Ameland, NL, Waddenzee (5); |
Habitat: detritus in salinic water (salinity 4-7%) (2); between green algae (Enteromorpha?) (3); on microslides covered with aufwuchs (4); between algae (5), together with Proales halophila; |
Date: 24.10.2016 (2); 07.08.2018 (3); 02.10.2018 (4); 18.10.2018 (5); |
|
|
